Parweld XTM 221Di MIG Inverter 5-in-1 | MIG, TIG and Plasma | P3T

PARWELD XTE 171C MIG WELDER

Ideal for light automotive and hobbyist use, the Parweld XTE range are a transformer machine with fan cooling. The XTE 171C is suitable for welding of Steel, Stainless Steel and Aluminium when using the appropriate MIG welding wire.  An incorporated wire feed of metal construction with a quality motor with 2 roll drive provides reliable wire feeding. Suitable for either 0.6 or 0.8mm MIG wire in 5 or 15kg spools.  8 step voltage selection and infinitely variable wire feed speed allows fine tuning of welding parameters. Industry standard euro torch connection allows the use of all good quality MIG torches.  Supplied with the Parweld Eco-grip Max 150A MIG torch, taking industry standard Binzel style spares available from any welding supplier. Perfect for in the workshop, the Parweld XTE machines are supplied on wheels and casters for maneuverability.  A solid rear wheel axle further demonstrates the machines rugged build quality.  A carriage at the rear of the machine securely holds half size (20L) gas cylinders.

KEY FEATURES

• Weld Steel, Stainless Steel or Aluminium
• 230V single phase
• 165A @ 15% duty cycle
• 2 roll drive wire feeder
• Use gas with solid MIG wire or reverse polarity and use gas less, self shielding MIG wire
• Forced fan air cooling
• 8 voltage step adjustment
• Infinitely variable wire feed speed
• Overload warning indicator
• Built in gas valve
• Use 5kg or 15kg MIG wire spools
• Supplied with Parweld MIG torch – Integrated Knuckle Joint Systems allowing movements of the handle and neck independently from the cable assembly
• 2 year return to base warranty
• Manufactured to IP21S, ISO/IEC 60974-1, ISO/IEC 60974-6 and RoHS Compliant

    SUPPLIED WITH:  Power source with euro connecting 3m Parweld Eco grip max 150A MIG torch, 1.65m hard wired work return lead, operating instructions

SPECIFICATION

Input Supply 50/60Hz	Fuse amps	Amperage range	Voltage steps	Wire size	Duty Cycle	Dimensions / Weight	Generator requirements (+/-15%)
230V	16A	30 – 165A	8	0.6 – 0.8mm	165A @15%	705 x 420 x 630 mm / 38.3kg	8kVA

Parweld XTM 211DI 4-in-1 Multi-Process MIG Inverter with AC/DC TIG & MMA

XTM 211DI Parweld Multiprocess – P1 Package Machine and MIG Torch Package

The Parweld XTM211Di is a 4-in-1 multi-process MIG inverter that also carries the capabilities for DC TIG, AC TIG and MMA, all in one machine. High quality build and excellent functionality for outstanding welding characteristics on every weld. The XTM211 DI is unique from other multi-mode MIG machines in that it comes equipped with capabilities for AC/DC TIG. This machine is also set up for hosting both a MIG and TIG torch at the same time, as well as quick switching between TIG and MIG, for swift and easy use. To switch to MIG from TIG, simply put down the TIG torch, pick up the MIG one and press the trigger. The XTM 211 will detect the change in torches and automatically switch over to the correct function for you. Vice versa is also true of the MIG to TIG torches. This functionality also extends to the gases too. You can have both Argon and Argon Mix plugged into the machine and the inverter will switch between the gases automatically based on which process it detects is being used.

Features:

Auto polarity switching inside. Changing the work lead connections on the front of the machine is a thing of the past. Instant swapping between MIG and TIG processes available with one touch of a torch trigger, thus perfect for a versatile workshop, able to switch between any job or any part of a job with the press of a button. Modern, multi-language digital user interface/display, alongside simple and intuitive selection options, allows for easy navigation through the synergic programs on board. Appropriate for workshop and sitework. Save and recall up to 9 job function settings for any desired process.

SPECIFICATION

Input Voltage (Smart Switching)	AC 110V – 50/60 Hz	AC 230V – 50/60 Hz
Min Fuse Rating	32A	16A
Input Power (kVA)	3.7	3.7
Max Current (A)	MIG 140  TIG  140 MMA 110	MIG  200  TIG  200 MMA 200
Duty Cycle @ 40’C		MIG 200A @ 25%
Generator size	7 kVA
Feed Roll	2 Roll
Wire Spool Size	300mm 15KG 200mm 5KG
Wire Size	0.6 – 1.0mm
Style	Portable
Machine Type	Inverter
Protection Class	IP23S
Dimensions	615 x 275 x 495
Weight (Kg)	27.8
