Parweld XTM 201i MIG Welder

It has a DC output and when combined with the correct type of wire it is suitable for welding steels. The feed box ensures reliable feeding of 0.6mm and 1.0mm wires. The XTE 201C has a full sized cabinet which can accept a gas cylinder and its large wheels mean it is easily portable and can be moved from job to job.

Parweld XTM 211DI 4-in-1 Multi-Process MIG Inverter with AC/DC TIG & MMA

XTM 211DI Parweld Multiprocess – P2 Package Machine, TIG Torch and MIG Torch Package

The Parweld XTM211Di is a 4-in-1 multi-process MIG inverter that also carries the capabilities for DC TIG, AC TIG and MMA, all in one machine. High quality build and excellent functionality for outstanding welding characteristics on every weld. The XTM211 DI is unique from other multi-mode MIG machines in that it comes equipped with capabilities for AC/DC TIG. This machine is also set up for hosting both a MIG and TIG torch at the same time, as well as quick switching between TIG and MIG, for swift and easy use. To switch to MIG from TIG, simply put down the TIG torch, pick up the MIG one and press the trigger. The XTM 211 will detect the change in torches and automatically switch over to the correct function for you. Vice versa is also true of the MIG to TIG torches. This functionality also extends to the gases too. You can have both Argon and Argon Mix plugged into the machine and the inverter will switch between the gases automatically based on which process it detects is being used.

Features:

Auto polarity switching inside. Changing the work lead connections on the front of the machine is a thing of the past. Instant swapping between MIG and TIG processes available with one touch of a torch trigger, thus perfect for a versatile workshop, able to switch between any job or any part of a job with the press of a button. Modern, multi-language digital user interface/display, alongside simple and intuitive selection options, allows for easy navigation through the synergic programs on board. Appropriate for workshop and sitework. Save and recall up to 9 job function settings for any desired process.   Superior arc control thanks to Pulse TIG function, for optimal heat control to ensure you don’t burn through your workpiece whilst welding it. Comes with HF (High Frequency) Start TIG ignition. Synergic programming makes working out your weld settings easier than ever – by simply inputting the material and thickness of your desired workpiece, the inbuilt programming automatically calculates the optimum settings for you. Alternatively, for fine-tuning and to suit the more experienced welder, a manual setting selection mode is also available. Connect to your smartphone via Bluetooth for modern control and parameter settings. Machine comes with MMA lead set, 3m MIG Torch with Amperage Control, 12.5ft TIG Torch with Amperage Control, input cable and two gas hoses as standard.

SPECIFICATION

Input Voltage (Smart Switching)	AC 110V – 50/60 Hz	AC 230V – 50/60 Hz
Min Fuse Rating	32A	16A
Input Power (kVA)	3.7	3.7
Max Current (A)	MIG 140 TIG  140 MMA 110	MIG  200 TIG  200 MMA 200
Duty Cycle @ 40’C		MIG 200A @ 25%
Generator size	7 kVA
Feed Roll	2 Roll
Wire Spool Size	300mm 15KG 200mm 5KG
Wire Size	0.6 – 1.0mm
Style	Portable
Machine Type	Inverter
Protection Class	IP23S
Dimensions	615 x 275 x 495
Weight (Kg)	27.8
